Features

Specifications

Condition: New

Raw Material Processed: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton Stalks

Pellet Diameter (mm): 4 - 15

Output (kg/h): 200 - 300 Kg/h

Voltage: 380V, 50HZ, 3PHASE

Dimension(L*W*H): 1560*850*1000

Warranty: 1 Year

Applicable Industries: Machinery Repair Shops, Farms, Home Use

Key Selling Points: Competitive Price

Weight (KG): 320 KG

Marketing Type: Ordinary Product

Machinery Test Report: Provided

Video Outgoing-inspection: Provided

Warranty Of Core Components: 1 Year

Core Components: Bearing

After-sales Service Provided: Engineers Available To Service Machinery Overseas, Online Support

Name:: Pellet Making Machine

Material:: Alloy Steel Of Pellet Making Machine Line

Raw Material:: Rice Husk, Straw, Sawdust, Hay, Etc.

Power Supply:: Electric Motor Of Wood Pellet Making Machine Price

Bearings:: FAG/NSK

Weight: 280/310 KG

Power(W): 22kw

After Warranty Service: Video Technical Support, No Service, Online Support, Spare Parts, Field Maintenance And Repair Service

Local ServiceÂ Location: None

Showroom Location: None

Certification: CE ISO

Basic Infomation

Certification: CE ISO

Payment & Shipping Terms

Packaging Details: Plywood case diesel engine feed pellet making machine

Supply Ability: 500 Set/Sets per Month diesel engine feed pellet making machine

Product Description

Product Application

Flat die animal feed pellet machine for farm is widely used for producing variety materials into high-grade aquatic feed pellets for fish, catfish, shrimps, crab etc.This dry type fish feed pelletizer has gained popularity in catfish farmers. And Flat die animal feed pellet machine is also used into animals feed pellets for sheep, cattle, poultry, goose, chicken and others.

SPECIFICATIONS FOR ANIMAL FEED PELLET MACHINE
Model	Wood chip production （t/h）	Feed production（t/h）	Engine(diesel/electric/gasoline)	Motor Power
LM125A	40-60 KG/H	60-100 KG/H	diesel	8HP
LM120B	40-60 KG/H	60-100 KG/H	electric	2.2KW 220V 50HZ 3KW 380V 50HZ
LM150A	50-100 KG/H	100-200 KG/H	diesel	8HP
LM150B	90-120 KG/H	150-220 KG/H	electric	4KW 380V 50HZ
LM150C	50-100 KG/H	100-200 KG/H	gasoline	13HP
LM200A	110-180 KG/H	220-350 KG/H	diesel	15HP
LM230A	150-200 KG/H	300-400 KG/H	diesel	22HP
LM230B	150-200 KG/H	300-400 KG/H	electric	380V 50HZ 11KW
LM260B	200-300 KG/H	400-600 KG/H	electric	15KW 380V 50HZ
LM300B	300-400 KG/H	600—800 KG/H	electric	22KW 380V 50HZ

Main Features

1) Varied driving power, electricty or diesel; environmentally friendly and energy saving.

2) Equipped with the clutch and accelerating-decelerating device to change its speed.

3) Made of wear-resistant material thus having a long service life.

4) Adopt screw-center adjusting pressure structure which makes flat die pellet mill more practical.

5) Can make different feed pellets to meet different production requirements.

6) Adjustable compression rate, the flat die pellet mill can meet different pelletizing requirements and is available to press coarse materials.

7) Can process various kinds of solid grain into small feed pellets for animals like fish, shrimps, chicken, rabbit, and pig; widely used in small aquaculture, grain feed factory, farm, poultry farm, as well as individual farmers.

8) The pelleting process is visible, so it is convenient to solve problems in time.

9) Simple structure, low consumption, small area coverage, easy operation and maintenance.

10) With Diesel flat die pellet mill you can make bedding pellets for animal stalls from cardboard.

Detailed Images

Structure drawing of internal parts of flat die machine

WE WILL SEND YOU THE MACHINE WITH THE MAINTANANCE GUIDEN BOOK ONCE YOU ORDER THIS MACHINE FORM OUR FACTORY.

AND ANY TECHNICAL SUPPORT PLEASE CONTACT US.

The detail about the spare parts, once you order form our factory ,you can get three molds for free. and we will always keep online of the aftersales service .
